8 in 1 RF QAM DVB-C Modulator hd 1080p@60fps h.264 ip encoder

FOB Reference Price:Get Latest Price
$1,000.00 - $3,999.00 / Set | 1 Set/Sets (Min. Order)
Lead Time:
Quantity(Sets) 1 - 1 2 - 5 >5
Est. Time(days) 3 7 Negotiable
Customization:
Customized logo (Min. Order: 5 Sets)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
Dibdvb
Model Number:
Q508M
Input:
8/12/16/20/24 HD-MI, ASI
Output:
IP, ASI, RF
Video encoding:
MPEG-4 AVC/H.264
Audio encoding:
MPEG-1 Layer 2
Q508/Q512/Q516/Q520/Q524:
12/16/20/24 SPTS, 1MPTS
Q508M/512M:
4 DVB-C/T/ATSC/ISDB-T, 8/12 SPTS, 1MPTS
Protocol:
Support UDP RTP Multicast Unicast
Application 1:
Digital TV Head-end System
Application 2:
Hotel System
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
Standard packing
Port
Shanghai
Lead Time :
Quantity(Sets) 1 - 1 2 - 5 >5
Est. Time(days) 3 7 To be negotiated
Detailed Images


Product Description

Q5 perfect video quality MPEG-4 AVC encoder modulator up to 24 HD-MI sources from Satellite Receiver, PC, Blue ray, Local Playout, the latest new device which integrate encoding (MPEG-4 AVC/H.264) and option modulation (DVB-C/ DVB-T/ ISDB-T/ ATSC/ DTMB) to convert Video/Audio signals into RF over exist Coax Cable distribution. A key feature of Q5 is an outstanding choice of inputs, programs input via ASI can also be multiplexed and remapped to the ASI output, adding yet another function to the unit as an ASI multiplexer.



Q5 is designed especially for high density Distribution Video Engineering project, which can support rapid deployment. It distribute any HD and SD of HD-MI Clear Video to unlimited TVs over the existing TV coax cables with real time perfect quality at any distance. Q5 already have been picked by well known companies not only because our high performance encoders ensure 100% uptime and stability of the system, but also because they come with advanced support for stable configuration, which is critically important to all live broadcasting applications.



Overall Dibsys 's encoder modulators perfectly suit any professional AV company, including TV Channels, Live broadcasters, AV Installers and Integrators, Government applications, Hotel, Campus, Entertainment facilities, education broadcasting systems at schools and government buildings and many others.

Highlights

  • Works both Coax Cable & IPTV networks: Distribute MPEG-4 AVC encoding to all kinds of Modulation and All SPTS/ MPTS
  • Over UDP IP out.
  • Operation via LCD Screen and Web Management: easy to read LCD color front panel that makes it easy to setup and monitor your channels, check firmware, and identify IP addresses without a computer.
  • Multi-Modulation: Optional DVB-C (QAM), DVB-T (COFDM), ATSC-T, ISDB-T, DTMB Modulation (can selectable in one device).
  • ASI Multiplexing Inputs and Outputs: Compatible with traditional ASI Ports connected in Digital TV headend Solution.
  • Flexible selection of different input modules: four tuner, four HD-MI encoding in one device.
Features
  • Distribute Up to 8/12/16/20/24 channels of High quality HD content over RF (DVB-T/DVB-C/DTMB/ISDB-T/ATSC) to an unlimited number of TVs
  • Optional DVB-C (QAM), DVB-T (COFDM), ATSC-T, ISDB-T, DTMB Modulation (can selectable in WEB management) 4*Carrier RF Out
  • Two separate ASI input for External TS Multiplexing
  • Simulaneously MPTS and SPTS over UDP/RTP IP out
  • Audio gain adjustment supported
  • 4 separate multiplexing and Up-converter modulating adjacent carrier out
  • Selectable the Value of PCR PID same as Video PID
  • VBR and CBR mode
  • LCN (Logical Channel Number) support
  • PSI/SI editing & inserting
  • Full HD 1080p60fps resolution Supported
  • Support PCR correct and PCR interval adjusting
  • Superior Shoulders and Excellent modulation quality MER
  • Low power consumption and high reliability with MTBF(Mean Time Between Failure) ≤87600 Hours
  • Easy-to-Use System Management via Web, front panel with LCD Display
  • Low Cost per channel -  Breakthrough Price !

Application

  • Digital TV headend Encoding Video solution
  • Works with Digital TV transmitter in wireless TV broadcasting
  • Upgrade all your analog Head-ends to digital TV Solution
  • Enterprise, Hotel, campus, hospital, Public Place
Specification



Encoder Part

HD-MI inputs

Numbers of Boards

4 HD-MI ports per module

Up to 6 Modules in Back panel

Numbers of Ports

8; 12; 16; 20; 24 Channels

DVB-ASI  inputs

Connector

BNC female, 75Ω

Signal Level

200-800mVp-p

Packet Length

188 bytes

Maximum bit-rate per port

≤100Mbps

Number of Input Ports

Dual separate ASI ports

Video Processing

Input/output Resolution

1920×1080_60p,1920×1080_50p

1920×1080_60i 1920×1080_50i

1280×720_60p, 1280×720_50p,

720x480, 720x576

Frame rate

 60fps,59.94fps,50fps

Encoding

MPEG-4 AVC (H.264) High Profile Level 4.0

Bit-rate

0.8Mbps~20Mbps

Rate Control

CBR,VBR

Audio Processing

Input

HD-MI embedded audio

Encoding

MPEG-1 audio Layer

Sampling rate

48KHz

Resolution

24-bit

Bit-rate

64kbps, 128Kbps, 192kbps,384kbps

Audio Gain

0-255

Multiplexing

Maximum PID Remapping       180 input per channel

PID remapping by automatically or manually

PSI/SI

SDI/PMT/TOT/PAT/BAT/CAT/TDT/NIT  Insert

Accurate PCR adjusting

Max Numbers

7 Group

4 RF output (4 RF can Separate mux)  in modulation  mode

1 IP (MPTS) out ( Separate modulation channels or  MTPS channels mux out)

Stream Output

DVB-ASI

2 Separate ASI, (Select from  modulation Channels or MPTS  channel)

75Ω, BNC, 188Bytes

MPEG-2 TS over DVB-ASI (EN 50083-9)

RJ45 Port

100/1000M GbE Port

Simultaneous output with N*SPTS (from HD-MI channels) and  1*MPTS ( modulation or MPTS channels)

MPEG-2 TS over UDP, unicast, and multicast streaming

MPEG-2 TS over RTP/RTSP

Configurable packet size(2-7)x188Bytes

Filter Null Packet

Total Bitrate

1-200Mbps (Should be More than Encoding bitrate)

Modulation Part

Connector

1 Port,  F-Type, 75

Output Return Loss

14 dB

MER

≥40dB

RF output level

-30 ~ -10dbm,0.1db step

RF frequency

47-860Mhz, 1KHz step

Numbers of RF Channe

4

Modulation Mode

DVB-C, DVB-T, ATSC, ISDB-T, DTMB

DVB-T Standard

EN300744

FFT mode

2K, 8K

Bandwidth

6M, 7M, 8M

Constellation

QPSK, 16QAM, 64QAM

Guard Interval

1/4, 1/8, 1/16, 1/32

FEC

1/2, 2/3, 3/4, 5/6, 7/8

DVB-C Standard        J83.A (DVB-C, J83.B, J83.C

Carrier

ANNEX A

Annex B

Annex C

Constellation(QAM)

16,32,64,128, 256

64

256

64/256

Bandwidth(Mhz)

8

6

6

6

Symbol Rate(Mbaud)

5-7

5.057

5.361

4.2-5.3

ISDB-T Standard

ARIB STD-B31

Constellation

DQPSK, QPSK, 16QAM, 64QAM

Guard Interval

1/32, 1/16, 1/8, 1/4

Transmission Mode

2K, 4K, 8K

Code rate

1/2, 3/4, 5/6, 7/8

BandWidth

 6Mhz

ATSC Standard 6Mhz

ATSC A/53

Constellation

8 VSB

DTMB Standard

GB20600-2006

Constellation

4QAM, 16QAM, 32QAM, 64QAM

Code rate

0.4, 0.6, 0.8

Guard Interval

420, 595, 945

System

Local interface

LCD + control buttons

Remote management

Web/NMS

NMS interface

RJ45, 100M

Language

English

Environment

Voltage range

100 to 120/200 to 240V AC ±10%; 50/60Hz

Power consumption

60W

Operation Temperature

0 ~ 45℃

Storage  Temperature

-20 ~ 80℃

Dimensions

482mm (L) * 380mm (W) * 44mm (H)

Weight

4.5 kg

Typical Order Information

Model

HD-MI

Modulation

IP out

Q504

4

NULL

4*SPTS/1*MPTS

Q508

8

Null

8*SPTS/1*MPTS

Q512

12

Null

12*SPTS/1*MPTS

Q516

16

Null

16*SPTS/1*MPTS

Q524

24

Null

24*SPTS/1*MPTS

Q504M

4

QAM; ATSC; DVB-T; ISDB; DTMB

4*SPTS/1*MPTS

Q508M

8

QAM; ATSC; DVB-T; ISDB; DTMB

8*SPTS/1*MPTS

Q512M

12

QAM; ATSC; DVB-T; ISDB; DTMB

12*SPTS/1*MPTS

Q516M

16

QAM; DVB-T; DTMB

16*SPTS/1*MPTS

Q524M

24

QAM

24*SPTS/1*MPTS

 Specifications are subject to change without notice.
